Flat Heat Press Machine

The working principle of the flat heat press is to output pictures on the transfer paper first, then transfer them onto flat sublimation blanks at appropriate temperature and pressure.

The flat heat press machine is mainly used to transfer portrait photos, landscape patterns, and personalized customized patterns onto various flat consumables, especially suitable for making medals, photo frames, personalized T-shirts, etc. It is economical and practical, with exquisite patterns.

Flat heat press machines are mainly divided into manual flat heat press machines, pneumatic flat heat press machines, and hydraulic flat heat press machines.

Any image that fits the size can be heat transferred and printed.

Simple operation, exquisite printing, and low production cost.

Can be used in industry and convenient for civilian use.

Low commodity wastage, high added value, and strong decorative craftsmanship.

Complies with green and environmentally friendly printing standards, with no environmental pollution.

For the selection of printing materials: it is necessary to use heat transfer ink and heat transfer paper, or ordinary ink to print on the heat transfer film; Cup, bottle, tumbler with sublimation coating.

Light color transfer paper is suitable for printing light colored clothes such as white; Dark transfer paper is suitable for printing dark clothes such as black.

There are three concepts on the flat heat press machine, namely pressure, temperature, and time.
Working mechanism: By using a heating plate to generate heat, a certain pressure, specific temperature, and time are used to apply the layer and thermosetting of the transfer paper onto the substrate or penetrate it onto the substrate.
(1) Adopting a microcomputer intelligent temperature controller/time integrated controller, with high accuracy (temperature accuracy up to ± 0.5 ° C);
(2) The heating wire and heating plate are cast as a whole, which is safe, durable, and evenly distributed with heat;
(3) The heating plate is coated with iron fluorine anti stick coating;
(4) Electronic time control, process completion signal alarm indication;
(5) Pressure can be adjusted freely;
(6) The bottom plate is equipped with high-temperature resistant foam silicone board, which can withstand a temperature of 350 ° C without deformation.

This model is designed as a high-end professional machine, using a dual channel, solid die-casting aluminum heating plate. It has a heavy-duty drawer guide rail that can be used to print the front and back of clothes, and has an automatic pop-up function. The entire machine uses a 3mm thick sheet metal frame, with some parts reaching a thickness of 4mm. The lower part is pressed with a mold spring, with even pressure and heating.
The dual heating tube design provides more uniform heating, with a temperature difference of only about 5 degrees between the center and edge temperatures, resulting in good transfer efficiency. Old style machine with wide spacing between heating tubes, with a temperature difference of over 10 degrees between the center and the edge.
